Pt100 RTD with Standard 3 Pin Plug
Pt100 RTD with Standard 3 Pin Plug
Description
RTD resistance thermometer (Pt100) with 316 Stainless
Steel sheath and 3 pin standard plug.
A Pt100 detector with 3.0mm, or 6.0mm diameter stainless
steel sheath as standard. This rigid stem probe is ideal for
general purpose temperature measurement giving the
element protection in air or liquids. It is suitable for fast
connection and disconnection.
The Pt100 sensing element is 10mm long and is placed at
the tip of the sheath which means that the minimum
immersion depth should be at least 50mm.
This probe features a convenient 3 pin standard connector
which is ideal for fast connection.
Specification
Features
Pt100 Class B
316 Stainless Steel
Low cost
High accuracy and repeatability
Ideal when quick disconnection is required
100 Ohm platinum RTD 3-wire element
Bespoke manufacture
Optional Class A, 1/10 DIN or Pt1000 available on
request
Application
Ideal for Quick Connect Applications
Water Treatment
Research & Laboratory
Test & Measurement
