Type 5090 – injection cooler
By incorporating the valve technology of the segment plate valve, the Type 5090 injection cooler is able to regulate steam pressure and temperature in the steam network in the simplest possible way. Using four injection nozzles and finely tuned water conditioning, superheated steam is used to generate process steam at 3-20 K above the saturated steam temperature.



By incorporating the valve technology of the segment plate valve, the Type 5090 injection cooler is able to regulate steam pressure and temperature in the steam network in the simplest possible way. Using four injection nozzles and finely tuned water conditioning, superheated steam is used to generate process steam at 3-20 K above the saturated steam temperature.
Nominal size:
DN 50
Nominal pressure:
PN 40 – Large standard spread thanks to the 4-nozzle system
Material:
Stainless steel 1.4571 / 1.4408
Temperature:
Media temperature: -60 ° C to 220 ° C
depending on the seal design
connections | Connection cooling water DN50Connection steam line (cooler) DN100 for flanges according to DIN EN 1092-1 form B |
Positioner | Digital positioner type 8049Positioner with integrated process controller type 8049 IPCPositioner type 8049 optionally in explosion-proof designPositioner with attachment according to NAMUR standard |
use | Injection water for steam cooling |
